Time:2021-03-23
The main alloying element of 7050 aluminum plate is zinc. Adding magnesium to the alloy containing 3%-75% zinc can form MgZn2 with significant strengthening effect, making the heat treatment effect of 7050 airplane grade aluminum far better than that of aluminum-zinc binary alloy. Unlike 7075 aircraft aluminum sheet, 7050 aluminum plate T7451 and T7651 has particularly strong corrosion resistance and can be used for high-stress structures with strong corrosion resistance. The main application of 7050 aluminum sheet is the lip mouth grille of aircraft.
Chemical compositionAlloy | Si | Fe | Cu | Mn | Mg | Cr | Zn | Zr | Ti |
7050 | 0.12 | 0.15 | 2.0-2.6 | 0.10 | 1.9-2.6 | 0.04 | 5.7-6.7 | 0.08-0.15 | 0.06 |
Alloy | Temper | Thickness | Width |
7050 | T7451 | 4-260mm | 1200-3800mm |
7050 | T7651 | 4-260mm | 1200-3800mm |
Alloy | state | Direction | Thickness (mm) | Tensile strength (Mpa) | Yield Strength (Mpa) | Breaking Elongation | Standard |
7050 | T7451 | L | 6-203 | 515-535 | 450-470 | 11.5-15.5 | AMS4050 |
7050 | T7451 | LT | 6-203 | 515-535 | 450-470 | 11-13.5 | AMS4050 |
7050 | T7451 | ST | 6-203 | 500-520 | 420-440 | 8-10.5 | AMS4050 |
7050 | T7651 | LT | 6-76 | 550-570 | 480-500 | 10-12.5 | AMS4201E |
Like other China 7050 aluminum plate suppliers, Haomei offers quotations based on the aluminium ingot price on the day of delivery and the manufacturing cost.
